EXS-100
Semi-Automatic Strapper
The semi-automatic EXS-100 strapping machine is designed to apply a plastic strap around your packages, preventing them from opening during handling and transit. The EXS-100’s bottom seal design is an ideal solution for low to medium volume users that need additional security beyond case taping.
SIMPLE AND EFFICIENT
Operating the EXS-100 strapping machine is easy and can be learned in minutes. The machine features an open cabinet design making it easy to view and change your poly strapping. The EXS-100 features electronic tension control, allowing the user to adjust the proper tension for a wide variety of packages, and the heated strap-weld sealing system ensures a secure strap.
INDUSTRIAL STRENGTH OPERATION
The system comes standard with four locking casters that allow for easy transportation within the facility. The EXS-100 is pre-configured to an industry standard height of 30”, making a comfortable fit for most packaging environments.
Features
- Small machine footprint allows for use almost anywhere within your facility
- Four locking casters for easy transportation
- Jog switch for service and maintenance
- Adjustable cooling time for various weld seals
- Open cabinet design allows for quick poly strapping changeover
- Adjustable packaging guides to allow for a variety of package sizes
- Electronically controlled tension adjustment
- One motor with no clutch, belt, or chain
- Motor power saving when strapping is not active
- Accepts straps ranging in width from 5mm–15.5mm
- Simple and efficient to use
- No air required
- Strap packages up to 130lbs
- 110V single phase power supply
EXS-100 Specs
- Strap Width – 0.2” – 0.6” (5mm-15.5mm)
- Strap Thickness – 0.02” – 0.027” (0.45mm – 0.7mm)
- Strap Core Diameter – 7.9” (200mm)
- Strap Core Width – 7.5”-7.9” (190mm -200mm)
- Strap Material – Polypropylene only
- Minimum Package Size – 2.75” (70mm) W x 0.79” (20mm)
- Maximum Package Weight – 130lbs (59kg)
- Speed – 1 meter/s for feeding; 1 meter/s for reversing
- Machine Tension – 2 -121lbs (1-55kg)
- Machine Dimensions – 21.4” (544mm) W x 30.7” (780mm) L x 30.7” (780mm) H
- Power Supply– 100V/110V, 50/60 Hz, 1 Phase
- Weight –117lbs (53kg)
Why Choose Adaptive?
As a distributor of Eastey packaging equipment, Adaptive supplies a full range of Eastey machines along with the films, strapping and consumables needed for day-to-day operation. Working with Adaptive means streamlined ordering, product knowledge and dependable access to both equipment and ongoing supplies.
For customers looking to go beyond standalone equipment, Adaptive also offers optional integration services. Whether connecting Eastey equipment to conveyors or incorporating it into a larger packaging system, integration can be provided at an additional cost based on project scope.
